Application Scope Of High-pressure Floating Ball Valves Manufacturers

The high-pressure floating ball valve includes a valve body, a medium inlet channel, a medium outflow channel, and a connection cavity provided on the valve body. The connection cavity is provided with a ball, and the valve body is provided with a connection hole that communicates with the connection cavity. There is a valve stem that is linked with the sphere, the valve stem is driven by the driving part, the medium inlet channel, and the medium outflow channel and the sphere is provided with seals, and the connecting hole is connected to the sphere.

There is an annular groove with a stepped cross-section between the connecting chambers, a step-shaped connecting block adapted to the annular groove is provided at one end of the valve stem and the ball, and the lower part of the annular groove is connected to the valve stem. Bearings are arranged between the stepped connecting blocks, and an O-ring and an elastic pressing piece are arranged between the upper part of the annular groove and the stepped connecting blocks of the valve stem.

Scope of application of High Pressure Floating Ball Valves Manufacturers: Floating ball valves are suitable for general industrial use, and are suitable for chemical, petroleum, natural gas, metallurgy, and other industries and for long-distance natural gas pipelines containing hydrogen sulfide, with many impurities and severe corrosion. Floating ball valves are divided into ordinary carbon steel series WCB, A105; stainless steel series 304, 316; low-temperature steel series LCB, LCC; anti-sulfur series, etc.
